Kodak Alaris S2060W Scanner

Model Name/Number

S2060w

Country of Origin

Made in India

Product Highlights

Network models, including wireless connectivity,

enable multiple users to easily share scanners in a

Throughput Speeds *

60 ppm / 120 ipm

Feeder Capacity

Up to 80 sheets of 80 g/m(20 lb.) paper

Connectivity

Network 802.11 b/g/n and 10/100 Ethernet

USB 3.2 Gen 1x1 USB 2.0 compatible Wireless

Network 802.11 b/g/n and 10/100 Ethernet

Maximum Document Size

216 mm x 3000 mm (8.5 in. x 118 in.)

Minimum Document Size

52 mm x 52 mm (2.08 in. x 2.05 in.)

Paper Thickness & Weight

27-433 g/m (7.2-160 lb.) paper Hard card thickness

up to 1.25 mm (0.05 in.)

Maximum Optical Capture Resolution

600 dpi

Accessories & Consumables

Stacking Deflector Accessory Integrated A4/Legal

Flatbed Passport Flatbed Accessory Carrier Sleeves

Acoustical Noise

Off or Ready mode: < 20 dB(A) Scanning: <50 dB(A)

Approvals and Product Certifications

Argentina (S mark) Australia/New Zealand (RCM) Canada (cTUVus & ICES-003) China (CCC) European Union

Barcode Reading

Codabar Code 128 Code 3 of 9 EAN-13 EAN-8

Interleaved 2 of 5 PDF417 QR UPC-A UPC-E

Bundled Software

Capture Pro Limited Edition Smart Touch

Data Security

This scanner processes scanned data exclusively through volatile memory ensuring image data is effec

Dimensions & Weight

Weight: 3.3 kg (7.2 lbs.) Depth: 204 mm (8.0 in.),

not including input tray and output tray Width: 3

Electrical Requirements

100-240 V (International); 50-60 Hz

Environmental Certification

2008 EuP ENERGY STAR Qualified EPEAT Gold

File Format Outputs

BMP JPEG Single-page TIFF Microsoft Excel Microsoft Word Multipage TIFF PDF Text searchable PDF PNG

Image Output Resolution Options

Up to 1200 dpi

Network Protocols

DHCP (or static IP) TCP/IP

Operating System Compatibility

WINDOWS Server 2016 X64 Editions WINDOWS Server 2012 R2 X64 Editions WINDOWS 7 SP1 (32-bit and 64-bi

Operating Temperature / Operating Humidity

Operating Temperature 10-35 Degree C (50-

95 Degree F) Operating Humidity 15% - 80% RH

Operator Control Panel

3.5 inch (89 mm) graphical color touchscreen

LCD with operator control buttons

Optional Software

Capture Pro Software Info Input Solution

Paper Handling (SurePath) Features

Controlled stacking Enhanced jam recovery Intelligent Document Protection Interactive multifeed with

Perfect Page Image Enhancement Software

Adaptive threshold processing Add or remove border Aggressive cropping Auto white balance Autocrop A

Power Consumption

Running: less than 36 watts Sleep Mode: less

than 5.0 watts Standby: less than 0.5 watts

Recommended Daily Volume

Up to 9,000 pages per day

Recommended PC Configuration

Minimum PC configuration with scanning application: Intel Core i3 processor or faster, at least 4 GB

Scanning Technology

Dual RGB LED Illumination CIS (CMOS); Grayscale output bit depth is 256 levels (8-bit); color output

Standard Software And Drivers

Citrix certified KOFAX certified ISIS Drivers LINUX (TWAIN and SANE) Drivers TWAIN Drivers WIA Drive

Minimum Order Quantity

2
